Description
The Proto J7208S is a 3/8 in drive, 1/4 in, 8-point impact socket. The manufacturer states that 8-point impact sockets suit stubborn or damaged fasteners and fasteners made from soft materials, and that impact sockets are used wherever powered drive tools install or remove fasteners.
Per the manufacturer, it is made from high-strength steel to keep the wall thin and reach fasteners in recesses, with tight tolerances for a snug fit, a drive end chamfer with four detents, and a side locking hole. Black oxide finish; nut depth 1/4 in, bolt clearance depth 1/2 in, overall length 1 in. Sizes are in inches. Sold as a single socket.
Features
- 3/8 in drive, 1/4 in, 8-point impact socket
- High-strength steel to limit wall thickness and reach recessed fasteners, per the manufacturer
- TorquePlus design engages the fastener flats rather than the corners, per the manufacturer
- Tight tolerances for a snug fit on the fastener, per the manufacturer
- Drive end chamfer with four detents and a side locking hole
- Size stamped on the tool
- Black oxide finish
- Size in inches (in), sold as a single socket
Specifications
| Specification | Value |
|---|---|
| Model | J7208S |
| Quantity | 1 piece |
| Type | 8-point impact socket |
| Drive size | 3/8 in |
| Size | 1/4 in (inch size) |
| Design | TorquePlus 8-point |
| Finish | black oxide |
| Bolt clearance depth | 1/2 in |
| Nut depth | 1/4 in |
| Drive end outside diameter | 11/16 in |
| Nut end outside diameter | 31/64 in |
| Overall length | 1 in |
| Weight | 0.03 kg (0.07 lbs) |
Part numbers
| Manufacturer part number (MPN) | Big Papa SKU |
|---|---|
| J7208S | BP-G-PRO-7208S |
