Description
The Starrett 124AZ is a solid-rod inside micrometer set with a 2-8 in (50-200 mm) range and .001 in graduations (0.01 mm / .001 in per the manufacturer), supplied with 6 measuring rods in a padded case. The manufacturer describes the 124 sets as useful for measuring inside diameters of cylinders and rings and for measuring parallel surfaces.
Per the manufacturer, the range is obtained by assembling the rods and a spacing collar to the micrometer head, and each rod has individual length adjustment for the anvil using the special wrenches furnished. Rods are solid, insulated and marked with their length, with hardened and ground anvils and quick-reading figures. Stated lead accuracy is +/- .0001 in per inch. This is a set, sold as one complete set.
Features
- Complete set: micrometer head, 6 solid measuring rods, spacing collar, wrenches and case
- Range 2-8 in (50-200 mm), .001 in graduations
- For inside diameters of cylinders and rings and parallel surfaces, per the manufacturer
- Range set by assembling rods and spacing collar to the head
- Individual anvil length adjustment on each rod with the wrenches furnished
- Insulated rods marked with length
- Hardened and ground anvils, quick-reading figures
- Lead accuracy +/- .0001 in per inch (as stated on the manufacturer page)
Specifications
| Specification | Value |
|---|---|
| Model | 124AZ |
| Quantity | 1 set |
| Type | mechanical inside micrometer set, solid rods |
| Range | 2-8 in (50-200 mm) |
| Graduations | .001 in (0.01 mm) |
| Accuracy | lead accuracy +/- .0001 in per inch (per the manufacturer) |
| Measuring rods | 6 (2-3, 3-4, 4-5, 5-6, 6-7, 7-8 in) |
| Spacing collar | one 1/2 in |
| Case | padded case |
| Weight | 0.59 kg (1.2 lbs, packed set, per the manufacturer) |
Part numbers
| Manufacturer part number (MPN) | Big Papa SKU |
|---|---|
| 124AZ | BP-G-STT-124AZ |
