Description
The Starrett DCH0156-G is a 1-5/16 in (33 mm) deep cut bi-metal hole saw with a threaded mount. It has hardened, heat-resistant, positive-rake high-speed steel teeth on an alloy backing, and a cutting depth of 2 in (51 mm).
It is intended for hand-held or fixed drills and is described by the manufacturer as suited to wood, metal and steel. NVP progressive pitch tooth geometry is designed to give a fast cut, good chip flow and smooth, low-vibration cutting. Requires a compatible arbor (A2-E or A10-E), sold separately. Sold as a single hole saw.
Features
- 1-5/16 in (33 mm) diameter with 2 in (51 mm) cutting depth
- Hardened HSS teeth with positive rake on an alloy body and cap
- NVP progressive pitch tooth geometry for chip flow and cutting rate
- For hand-held drills and drill presses
- Cuts metals, stainless, cast iron, wood, plastic, fiberglass and plaster (per the manufacturer)
Specifications
| Specification | Value |
|---|---|
| Model | DCH0156-G |
| Quantity | 1 piece |
| Type | deep cut bi-metal hole saw |
| Diameter | 1-5/16 in (33 mm) |
| Cutting depth | 2 in (51 mm) |
| Teeth per inch | 4-6 |
| Thread size | 5/8-18 |
| Arbor type | A2-E or A10-E |
| Body material | steel |
| Color | yellow |
| Weight | approx. 0.23 kg (per the manufacturer) |
Part numbers
| Manufacturer part number (MPN) | Big Papa SKU |
|---|---|
| DCH0156-G | BP-G-STT-DCH0156G |
